bitzer industrial refrigeration compressor 6FE-50(6F-50.2)

FOB Price:

US 700-19000 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

3000 Piece/Pieces per Month

Port:

Shanghai / Ningbo

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,T/T,Western Union,MoneyGram

Brand:

Bitzer(bitzer industrial refrigeration compressor 6FE-50(6F-50.2))

Products Model:

6FE-50

Products Details
Company Profile

Quick Details

Brand Name: Bitzer(bitzer industrial refrigeration compressor 6FE-50(6F-50.2))

Model Number: 6FE-50

Place of Origin: Zhejiang, China (Mainland)
Type: Compressor, bitzer industrial refrigeration compressor 6FE-50(6F-50.2)
Certification: CE, ROHS
After-sales Service Provided: Overseas third-party support available
Warranty: 1 year guarantee
Voltage: 380v-420v /3 Ph / 50Hz
Horsepower: 50HP
Number of Cylinder: 6
Gas: R22 / R404a/R134a
Configuration: Stationary
Power Source: AC Power
Weight: 241kgs
Oil: Mineral oil / Polyester Oil

Packaging & Delivery

Packaging Details: Plywood / Wooden box packing
Delivery Detail: 1-7 days

Specifications

Company Information

1. We are first level agent for Bitzer offering you competitive price.

2. We have all Bitzer Models available.

3. We prodive fast delivery within 1-7 days after payment.

4. We provide perfect after sales service.

5. We have regular clients of Bitzer product from both home and abroad.

Product Description

Features

1) New valve plate design

New geometric concept for pressure valves – for low rear expansion.
High cooling capacity with minimal energy requirements.
The ECOLINE cylinder head system: Flexible operation in tandem.

2) Motor

Efficient under full- and part-load thanks to its broadband characteristics.
The universal refrigeration compressor: Motor version 2 for medium and low temperature applications.
Motor versions 1 and 3 for special applications.

3) Capacity control

The CRII system – intermittent blocked suction For example, 4-cylinder compressor with CRII on both heads: Range of control from 100% to ~10%
ECOLINE VARISPEED – built-in frequency inverter

4) Downward compatible

Essential internal components completely redesigned.
Outer contour as standard: Every ECOLINE is downward compatible

5) Drive gear

New piston and connecting rod design

Technical Data

Technical Data of bitzer industrial refrigeration compressor 6FE-50(6F-50.2)

	SI	IP
Displacement (1450 RPM 50Hz)	151,6 m³/h	5353.7 CFH
Displacement (1750 RPM 60Hz)	183,07 m³/h	6462.6 CFH
No. of cylinder x bore x stroke	6 x 82 mm x 55 mm	6 x 3.23 inch x 2.17 inch
Weight	241 kg	531 lb
Max. pressure (LP/HP)	19 / 32 bar	275 / 464 psi
Connection suction line	54 mm - 2 1/8''	54 mm - 2 1/8''
Connection discharge line	42 mm - 1 5/8''	42 mm - 1 5/8''
Oil type R134a/R407C/R404A/R507A/R407A/R407F	BSE32(Standard) / R134a tc>70°C: BSE55 (Option)	BSE32(Standard) / R134a tc>155°F: BSE55 (Option)
Oil type R22 (R12/R502)	B5.2(Option)	B5.2(Option)

Extent of delivery(Standard) of bitzer industrial refrigeration compressor 6FE-50(6F-50.2)

	SI	IP
Motor protection	SE-B2	SE-B2
Enclosure class	IP54 (Standard), IP66 (Option)	IP54 (Standard), IP66 (Option)
Vibration dampers	Standard	Standard
Oil charge	4,75 dm³	167.2 fl oz

Motor Data of bitzer industrial refrigeration compressor 6FE-50(6F-50.2)

	SI	IP
Motor version	1	1
Motor voltage (more on request)	380-400V PW-3-50Hz	440-480V Y-3-60Hz UL
Max operating current	96.2 A	96.2 A
Winding ratio	50/50	50/50
Starting current (Rotor locked)	226.0 A Y / 404.0 A YY	425.0 A

Sound Measurement of bitzer industrial refrigeration compressor 6FE-50(6F-50.2)

	SI	IP
Sound power level (+5°C / 50°C)	83,9 dB(A) @50Hz	86,4 dB(A) @60Hz
Sound power level (-10°C / 45°C)	82,8 dB(A) @50Hz	85,3 dB(A) @60Hz
Sound power level (-35°C / 40°C)	90,5 dB(A) @50Hz	93 dB(A) @60Hz
Sound pressure level @ 1m (+5°C / 50°C)	75,9 dB(A) @50Hz	78,4 dB(A) @60Hz
Sound pressure level @ 1m (-10°C / 45°C)	74,8 dB(A) @50Hz	77,3 dB(A) @60Hz
Sound pressure level @ 1m (-35°C / 40°C)	82,5 dB(A) @50Hz	85 dB(A) @60Hz
Sound power level (+5°C / 50°C) R134a	81,9 dB(A) @50Hz	84,4 dB(A) @60Hz
Sound power level (-10°C / 45°C) R134a	80,8 dB(A) @50Hz	83,3 dB(A) @60Hz
Sound pressure level @ 1m (+5°C / 50°C) R134a	73,9 dB(A) @50Hz	76,4 dB(A) @60Hz
Sound pressure level @ 1m (-10°C / 45°C) R134a	72,8 dB(A) @50Hz	75,3 dB(A) @60Hz
